Lg Solar Panel, LG400N2W-A5, Neon2, 400W, 1000-1500V, 72 Cell

SV Code: 544651953987Model No.: LG400N2W-A5

1000-1500 VAC2 x 1200 mmGlassAnodized AluminiumIP68

AED 1,283.00/ Piece

Price includes VAT· Sign in to see your account priceMore Details

Out of stock

Return or exchange within 30 days of delivery.Sign in to see your account price and place orders.

Key features

Enhanced Performance Warranty. High Power Output.
Roof Aesthetics. Outstanding Durability.
Improved Performance on Sunny Days. Near Zero LID (Light Induced Degradation)
Electrical Properties at Nominal Operating Cell Temperature: Maximum Power Pmax-296W, MPP Voltage Vmpp: 37.6V, MPP Current Impp: 7.88A, Open Circuit Voltage Voc: 46.1V, Short Circuit Current Isc: 8.41A
Junction Box: IP68 with 3 Bypass Diodes
Maximum System Voltage: 1,500(UL) / 1,000(IEC)

Full description & specifications ↓

Fast delivery Genuine & warranty Bulk quotes

Specifications

SV Code	544651953987
Brand	Lg
Category	Solar Panels
Unit	Piece
Voltage	1000-1500 VAC
Short Circuit Current	10.47 A
Open Circuit Voltage	49.3 V
MPP Voltage	40.6 V
Maximum Power Point Current	9.86
Efficiency	19.3%
Size (dimensions)	161.7 x 161.7 mm
Cable Length	2 x 1200 mm
Material	Glass
Material Glassframe	Anodized Aluminium
Amps	20 A
Operating Temp	-40 to 90 Deg.C
Connector Type	MC4
Cell Type	Monocrystalline
No Of Sells	72
Country of Manufacture	South Korea
Brand Origin (not manufacture)	Korea
Delivery	Not on the shelf right now; 7 working days to source and deliver.

Description

The LG Neon 2 is LG’s best-selling solar module. The 72 cell-version of the Neon 2 is especially suited for commercial or utility applications, as it makes space management easier while maximizing power.

Features

Enhanced Performance Warranty. High Power Output.
Roof Aesthetics. Outstanding Durability.
Improved Performance on Sunny Days. Near Zero LID (Light Induced Degradation)
Electrical Properties at Nominal Operating Cell Temperature: Maximum Power Pmax-296W, MPP Voltage Vmpp: 37.6V, MPP Current Impp: 7.88A, Open Circuit Voltage Voc: 46.1V, Short Circuit Current Isc: 8.41A
Junction Box: IP68 with 3 Bypass Diodes
Maximum System Voltage: 1,500(UL) / 1,000(IEC)
Certification : ISO, UL, SGS, VdS
