Telwin Maxima 190 Synergic MIG/MAG Electrode Welding Machine, 816086, 1 Phase, IP23, 230V

(No reviews yet) Write a Review
Brand:
Telwin
SKU:
489525419562
Minimum Purchase:
1 unit
Item Name:
Electrode Welding Machine
Product Series:
Maxima 190 Synergic
Manufacturer:
Telwin
For Use With:
Steel, stainless steel, aluminium
Accuracy:
20%
Power Consumption:
3.2kW
Welding Current Range - Amps:
20-170A
Efficiency:
86%
Voltage:
230V
Max No Load Voltage:
44V
Measuring Current Range - DC:
80-140A
Fuse:
16A
Frequency:
50/60Hz
Ingress Protection (IP Rating):
IP23
Accessories Included:
1x Cable (16 MMQ 1.8 Mtrs), 1x Toledo 250 Work Clamp 250A, 1x TW180 MIG Torch (2.5 Mtrs)
Brand Origin (not manufacture):
Italy
Product Size L x B x H (Cms):
45L X 23.5B X 37H
Delivery Time:
2-7 Days
Unit:
Piece
See Full Product Specs
  • Telwin Maxima 190 Synergic MIG/MAG Electrode Welding Machine, 816086, 1 Phase, IP23, 230V
  • Telwin Maxima 190 Synergic MIG/MAG Electrode Welding Machine, 816086, 1 Phase, IP23, 230V
AED2,494.00
FREE DELIVERY

Description

Microprocessor controlled MIG-MAG/FLUX/BRAZING inverter wire welding machine. It allows great versatility in the use of various types of materials (steel, stainless steel, aluminium) and in all possible applications, from maintenance to installation works. The SYNERGIC adjustment of the welding parameters makes the products easy to use and grants excellent results, always, also for the less experienced operator.
  • Light and compact
  • It Can Be Easily Carried In Any Intervention Place, Both Inside and Outside
  • Polarity Reversal For Gas Mig-Mag/Brazing Welding
  • Thermostatic, overvoltage, Undervoltage, Motor generator (+/- 15%) Protections
  • Complete With Mig-Mag Torch, Work Clamp And Cable
  • Fit For No Gas/Flux Welding, It Can Be Transformed Into Mig-Mag With The Optional Kit
  • Absorbed Power At: 60%1.6kW
  • Max Absorbed Current: 22 A
  • Max Absorbed Current: 22 A
  • Steel Welding Wire Diameter: 0.6 - 0.8mm
  • Inox Welding Wire Diameter: 0.8mm
  • Aluminium Welding Wire Diameter: 0.8 - 1mm
  • Flux Cored Welding Wire Diameter: 0.8 - 1.2mm
Item Name:
Electrode Welding Machine
Product Series:
Maxima 190 Synergic
Manufacturer:
Telwin
For Use With:
Steel, stainless steel, aluminium
Accuracy:
20%
Power Consumption:
3.2kW
Welding Current Range - Amps:
20-170A
Efficiency:
86%
Voltage:
230V
Max No Load Voltage:
44V
Measuring Current Range - DC:
80-140A
Fuse:
16A
Frequency:
50/60Hz
Ingress Protection (IP Rating):
IP23
Accessories Included:
1x Cable (16 MMQ 1.8 Mtrs), 1x Toledo 250 Work Clamp 250A, 1x TW180 MIG Torch (2.5 Mtrs)
Brand Origin (not manufacture):
Italy
Product Size L x B x H (Cms):
45L X 23.5B X 37H
Delivery Time:
2-7 Days
Unit:
Piece
