Sanwa Digital Multimeter, CD800A, 4000 Counts
- Brand:
- Sanwa
- SKU:
- 589921784488
- Minimum Purchase:
- 1 unit
- Item Name:
- Digital Multimeter
- Model:
- CD800A
- Manufacturer:
- Sanwa
- Resistance Accuracy:
- +/-(1.5%+5)
- Bandwidth:
- 40 to 400Hz
- Display Type:
- Numerical
- Width (MilliMeter):
- 104 mm
- Height (MilliMeter):
- 176 mm
- Depth:
- 46 mm
- Battery Type:
- R6P x 2
- Measuring Voltage Range - AC:
- 4-600V
- Measuring Voltage Range - DC:
- 400mV-600V
- Storage Temperature:
- -10 to 50 Deg.C (>70% RH)
- Measuring Current Range - DC:
- 40m-400mA
- Measuring Current Range - AC:
- 40m-400mA
- Measuring Capacitance Range:
- 50nF-100 microfarad
- DC Voltage Accuracy:
- +/-(0.7%+3)
- AC Voltage Accuracy:
- +/- (1.6%+9)
- Frequency Accuracy:
- +/-(0.5%+3)
- Capacitance Accuracy:
- +/-(5.0%+10)
- Measuring Resistance Range:
- 400-40mohm
- Measuring Frequency Range:
- 5Hz-100kHz
- Fuse:
- 0.5A/250V 1.5kA Dia 5.2x20 mm
- Brand Origin (not manufacture):
- Japan
- Product Size L x B x H (Cms):
- 10.4L x 4.6B x 17.6H
- Delivery Time:
- 2-7 Days
- Unit:
- Piece
Description
This instrument is portable multimeter designed for the measurement of low-voltage circuit. This is used at small communications equipments, home electric appliances, voltage of lump line, and measurement of various types of batteries.
Items Included:
Instruction manual, Hand strap
View AllClose
- 3-3/4 digits 4000 count
- 0.7% best accuracy
- Capacitance measurement
- Frequency measurement (AC sine wave only)
- Data hold and Range hold
- Relative value
- Auto power off (30min.)
- Low power ohm (input voltage 0.4V) at continuity range
- Solid & protective body cover that can also be used as a tilt stand
- Chip holder behind the body cover
Items Included:
Instruction manual, Hand strap
