Telwin PTE 18 LCD Spot Welding Machine, 824050, 2 Phase, IP20, 400V
(No reviews yet)
Write a Review
- Brand:
- Telwin
- SKU:
- 643624484259
- Minimum Purchase:
- 1 unit
- Item Name:
- Spot Welding Machine
- Product Series:
- PTE 18 LCD
- Manufacturer:
- Telwin
- Voltage:
- 400V
- Max No Load Voltage:
- 2.6V
- Input Voltage Frequency:
- 50-60Hz
- Duty Cycle:
- 15 Percent
- Thickness (MilliMeters):
- 3mm
- Ingress Protection (IP Rating):
- IP20
- Accessories Included:
- 1x ARM (L: 350mm), 1x Standard Straight Electrode Xp
- Brand Origin (not manufacture):
- Italy
- Certification:
- EAC
- Product Size L x B x H (Cms):
- 79L x 32B x 128H
- Delivery Time:
- 2-7 Days
- Unit:
- Piece
Description
Telwin PTE 18 LCD 400V is a column spot welding machine with movable arms, microprocessor digitally controlled.
View AllClose
- The digital, multifunction LCD control panel allows to operate: in EASY mode (setting of spot welding current and time); in EXPERT mode (setting of different spot welding parameters) storing up to 20 customised programmes.
- It operates both in continuous and pulse mode and grants optimum results on different kinds of steel
- Adjustment of spot welding current (percent), time (cycles), force of electrodes compression
- Choice of various parameters of the spot welding cycle (approach, slope, welding and pause time and pulse number)
- Easy to read LCD display
- Mechanical pedal control
- Thermal protection with indicator
- The model requires water cooling for electrodes and arms
- Max spot-welding current: 9700A
- Rated power (X) 50 percent: 22kW
- Max electrodes power: 190 daN
- Arms projection: 330mm
Item Name: |
Spot Welding Machine |
Product Series: |
PTE 18 LCD |
Manufacturer: |
Telwin |
Voltage: |
400V |
Max No Load Voltage: |
2.6V |
Input Voltage Frequency: |
50-60Hz |
Duty Cycle: |
15 Percent |
Thickness (MilliMeters): |
3mm |
Ingress Protection (IP Rating): |
IP20 |
Accessories Included: |
1x ARM (L: 350mm), 1x Standard Straight Electrode Xp |
Brand Origin (not manufacture): |
Italy |
Certification: |
EAC |
Product Size L x B x H (Cms): |
79L x 32B x 128H |
Delivery Time: |
2-7 Days |
Unit: |
Piece |
