ABB Switch Disconnector, SHD204-25, 4P, 25A
- Brand:
- Abb
- SKU:
- 182787635391
- Minimum Purchase:
- 1 unit
- Item Name:
- Switch Disconnector
- Model:
- SHD204-25
- Manufacturer:
- Abb
- Color:
- White
- Pollution Degree:
- 3 Degree
- Manufacture Part Number:
- 2CDD274111R0025
- Number of Poles:
- 4P
- Voltage:
- 12-415V
- Frequency:
- 50/60Hz
- Height (MilliMeter):
- 85mm
- Width (MilliMeter):
- 70mm
- Depth:
- 69mm
- Torque (Nm):
- 2 Nm
- Short Circuit Current:
- 10 kA
- Ingress Protection (IP Rating):
- IP20
- Storage Temperature:
- -40 to 70 Deg.C
- Current:
- 25A
- Terminal Type:
- Screw
- Operational Voltage:
- 415VAC
- Brand Origin (not manufacture):
- Germany
- Delivery Time:
- 2-7 Days
- Unit:
- Piece
Description
ABB switch disconnector is a part of an equipment for disconnecting electronically from the high voltage line. With it, you can safely and properly conduct interruption of power supply.
View AllClose
- Rated Impulse Withstand Voltage: 4 kV
- Power Loss: 1.58W (at Rated Operating Conditions per Pole)
- Electrical Endurance: 20000 AC cycle
- Mechanical Endurance: 20000 cycle
- Overvoltage Category: III
- Actuator Type: Toggle
- Recommended Screw Driver: Pozidriv 2
- Width in Number of Modular Spacings: 4
Item Name: |
Switch Disconnector |
Model: |
SHD204-25 |
Manufacturer: |
Abb |
Color: |
White |
Pollution Degree: |
3 Degree |
Manufacture Part Number: |
2CDD274111R0025 |
Number of Poles: |
4P |
Voltage: |
12-415V |
Frequency: |
50/60Hz |
Height (MilliMeter): |
85mm |
Width (MilliMeter): |
70mm |
Depth: |
69mm |
Torque (Nm): |
2 Nm |
Short Circuit Current: |
10 kA |
Ingress Protection (IP Rating): |
IP20 |
Storage Temperature: |
-40 to 70 Deg.C |
Current: |
25A |
Terminal Type: |
Screw |
Operational Voltage: |
415VAC |
Brand Origin (not manufacture): |
Germany |
Delivery Time: |
2-7 Days |
Unit: |
Piece |
