Mitutoyo Outside Micrometer W/ Interchangeable Anvils, 104-136A, Range 150-300MM
(No reviews yet)
Write a Review
- Brand:
- Mitutoyo
- SKU:
- 134266294154
- Minimum Purchase:
- 1 unit
- Item Name:
- Outside Micrometer
- Model:
- 104-136A
- Manufacturer:
- Mitutoyo
- Accuracy:
- ±(4+L/75) µm
- Graduation:
- 0.01mm
- Measuring Range:
- 150-300mm
- Brand Origin (not manufacture):
- Japan
- Delivery Time:
- 2-7 Days
- Unit:
- Piece
Description
This analog outside micrometer offers you an extra wide measuring range and presents you with Easy, interchangeable anvils allow a wide range of measurements. Ratchet stop delivers a constant measuring force.
View AllClose
- 6 Interchangeable anvils
- Measuring surfaces - Hardened, lapped (anvil), carbide tipped, lapped (spindle side)
- Measuring spindle with spindle lock, ø 6,35 mm (up to 300 mm) ø8 mm (over 300 mm), spindle pitch 0.5 mm
- Thimble and sleeve satin chrome finish ø 18 mm scale
- Flatness: 0.6 µm, Parallelism: (2+L/100) μm, Measuring Force: 5-10 N
- 6 Setting standard
Item Name: |
Outside Micrometer |
Model: |
104-136A |
Manufacturer: |
Mitutoyo |
Accuracy: |
±(4+L/75) µm |
Graduation: |
0.01mm |
Measuring Range: |
150-300mm |
Brand Origin (not manufacture): |
Japan |
Delivery Time: |
2-7 Days |
Unit: |
Piece |
