Tridonic PC Square Basic High Frequency Ballast, 24138831, 13W, 220-240V, IP20
(No reviews yet)
Write a Review
- Brand:
- Tridonic
- SKU:
- 829479528935
- Minimum Purchase:
- 1 unit
- Item Name:
- Ballast
- Manufacturer:
- Tridonic
- Color:
- White
- Manufacture Part Number:
- PC1x4-13WBASIC
- Length:
- 80mm
- Width:
- 40mm
- Depth:
- 21mm
- Voltage:
- 220-240V
- Wattage:
- 13W
- Ingress Protection (IP Rating):
- IP20
- Brand Origin (not manufacture):
- Austria
- Delivery Time:
- 2-7 Days
- Unit:
- Piece
Description
A Tridonic Square High Frequency Ballast that offers energy-efficient operation of with 4W to 13 Watt Single T5, 2D and PLT/C Fluorescent Lamps. Features include automatic shutdown at end of life, 25000 starts, noise-free operation, low energy consumption and a 50000 hour lifespan.
View AllClose
- CELMA Energy Efficiency Index A2
- Large temperature range
- Automatic start after replacement of defective lamps
- Safety shutdown of defective lamps and at end of life
- Temperature protection as per EN 61347-2-3 C5e
- Lamp power: 3.5W
- Circuit power: 5W
- Hole spacing depth: 70mm
- Control gear technology: Fluorescent
- Non-dimmable
- Number of lamp: single
- Lamp: T5: 4,6,8,13w TC-D: 10w
- AC voltage: 198-264V and DC voltage: 176-264V
- Overvoltage protection: 270VAC
- Ambient temperature: - 25 to 50 Deg.C
Item Name: |
Ballast |
Manufacturer: |
Tridonic |
Color: |
White |
Manufacture Part Number: |
PC1x4-13WBASIC |
Length: |
80mm |
Width: |
40mm |
Depth: |
21mm |
Voltage: |
220-240V |
Wattage: |
13W |
Ingress Protection (IP Rating): |
IP20 |
Brand Origin (not manufacture): |
Austria |
Delivery Time: |
2-7 Days |
Unit: |
Piece |
