Karam Carabiner, PN113, Alloy Steel, 22.5MM, Gold
(No reviews yet)
Write a Review
- Brand:
- Karam
- SKU:
- 571377879268
- Minimum Purchase:
- 1 unit
- Item Name:
- Carabiner
- Model:
- PN113
- Manufacturer:
- Karam
- Material:
- Alloy Steel
- Color:
- Gold
- Finish:
- Golden Yellow Galavanized
- Diameter (MilliMeter):
- 11mm
- Average Breaking Strength (Kgs):
- 40kN
- Brand Origin (not manufacture):
- India
- Standards:
- EN 362:2004 Class B
- Delivery Time:
- 2-7 Days
- Unit:
- Piece
Description
- Oval shaped Karabiner made of dia 11 mm round bar
- Self-closing and automatic locking type karabiner
- Steel quarter turn locking karabiner
- Able to withstand a Tensile Load of 15 kN for 3 Min. with Gate closed and unlocked. And also able to withstand a Tensile Marked Load of 23 kN for 3 Min. with Gate closed and locked
- Able to withstand a Tensile Load of 7 KN for 3 Min
- With the gate closed and locked, apply a load of 6 kN per 10 second along the major axis. Unload and check that gate opens as intended
- Tested with a force of 1 kN per 90 sec, the gate locking feature of connector function correctly
- Gate locking withstands a force of 1.5 kN for 60 sec without any partial fracture. After this test the gate locking feature still functions correctly
- ISO 9227:2010-24 hours neutral salt spray followed by 1 hour drying, then a further 24 hours exposure
- No visual evidence of any corrosion present. Gate function retained
- Gate Opening: 22.5mm
Item Name: |
Carabiner |
Model: |
PN113 |
Manufacturer: |
Karam |
Material: |
Alloy Steel |
Color: |
Gold |
Finish: |
Golden Yellow Galavanized |
Diameter (MilliMeter): |
11mm |
Average Breaking Strength (Kgs): |
40kN |
Brand Origin (not manufacture): |
India |
Standards: |
EN 362:2004 Class B |
Delivery Time: |
2-7 Days |
Unit: |
Piece |
