Long Valve Regulated Lead Acid Battery, WP22-12NE, 12V, 22Ah
(No reviews yet)
Write a Review
- Brand:
- Long
- SKU:
- 431791834448
- Minimum Purchase:
- 1 unit
- Item Name:
- Valve Regulated Lead Acid Battery
- Model:
- WP22-12NE
- Manufacturer:
- Long
- Color:
- Black
- Resistance:
- 9 mohm
- Battery Voltage:
- 12V
- Battery Capacity:
- 22Ah
- Overall Height:
- 167 +2-1mm
- Discharge Current:
- 5 seconds: 330A
- Rechargeable:
- Yes
- Case Material:
- ABS UL94 HB Option: Flammability resistance of (UL94 V-0)
- Battery Life:
- 3-5 Years
- Terminals:
- F8
- Length (MilliMeter):
- 181 +2-1mm
- Width (MilliMeter):
- 76 +2-1mm
- Height (MilliMeter):
- 167 +2-1mm
- Brand Origin (not manufacture):
- Taiwan
- Delivery Time:
- 2-7 Days
- Unit:
- Piece
Description
- Nominal Capacity: 20 hour rate (1.1A to 10.5V) 22Ah, 10 hour rate (2.09A to 10.5V) 20.9Ah, 5 hour rate (3.74A to 10.2V) 18.2Ah, 1 C (22A to 9.6V) 12.47Ah, 3 C (66A to 9.6V) 8.8Ah
- Charging Methods at 25 Deg.C(77 Deg.F): Cycle use: Charging Voltage - 14.4 to 15V, Coefficient -5.0mV/Deg.C/cell, Maximum Charging Current: 6.6A, Standby use: Float Charging Voltage - 13.5 to 13.8V, Coefficient -3.0mV/Deg.C/cell
- Charge Retention (shelf life) at 20 Deg.C(68 Deg.F): 1 month 92%, 3 month 90%, 6 month 80%
Item Name: |
Valve Regulated Lead Acid Battery |
Model: |
WP22-12NE |
Manufacturer: |
Long |
Color: |
Black |
Resistance: |
9 mohm |
Battery Voltage: |
12V |
Battery Capacity: |
22Ah |
Overall Height: |
167 +2-1mm |
Discharge Current: |
5 seconds: 330A |
Rechargeable: |
Yes |
Case Material: |
ABS UL94 HB Option: Flammability resistance of (UL94 V-0) |
Battery Life: |
3-5 Years |
Terminals: |
F8 |
Length (MilliMeter): |
181 +2-1mm |
Width (MilliMeter): |
76 +2-1mm |
Height (MilliMeter): |
167 +2-1mm |
Brand Origin (not manufacture): |
Taiwan |
Delivery Time: |
2-7 Days |
Unit: |
Piece |
