Euroboor Magnetic Drilling Machine, ECO.100S+/CT, 2200W, 220-240V, 100MM Cutting Dia

(No reviews yet) Write a Review
Brand:
Euroboor
SKU:
137296345771
Minimum Purchase:
1 unit
Item Name:
Magnetic Drilling Machine
Model:
ECO.100S+/CT
Manufacturer:
Euroboor
Color:
Grey and Black
Voltage:
220-240V
Frequency:
50-60Hz
Length:
497mm
Height:
793mm
Width:
375mm
Cutting Diameter:
12-100mm
Countersink Diameter:
10-105mm
Twist Drill Diameter:
1-32mm
Connection Size:
19.05mm
Stroke Width:
260mm
Maximum Height:
793mm
Minimum Height:
615mm
Rotation Angle:
Bidirectional
Magnetic Force:
4300 Kg
Motor Power:
1900W
Total Power:
2200W
Power Source Type:
Electric
Brand Origin (not manufacture):
Netherlands
Delivery Time:
2-7 Days
Unit:
Piece
See Full Product Specs
AED10,944.00
AED8,026.00
— You save AED2,918.00

Description

The Euroboor ECO.100S+/CT magnetic core drilling machine cuts holes up to 100mm and is particularly suited for tapping and milling tasks that require high precision. The Cross Table provides exceptional control, allowing you to position the machine accurately across a range of 110mm (x-axis) and 120mm (y-axis) after the magnet is fixed to the surface. The spindle, secured by a threaded retaining ring, ensures the strongest coupling to the motor, minimizing play during demanding operations and enhancing accuracy. With its dynamic positioning feature, you can efficiently create slots and handle more complex workpieces without switching tools. The powerful 1900W motor, paired with an oil-lubricated four-speed gearbox and advanced electronics, ensures safe, reliable performance across various tasks.
  • Cross table base to give dynamic positioning during drilling procedure over a range of 110mm (x-axis) and 120mm (y-axis)
  • Milling feature to create slots and work on complex workpieces
  • Switch to tapping to create perfectly centered threads, while machine stays fixed on workpiece
  • Strong dual coil CNC machined 2-way magnet, causing the machine to use less energy, generate less heat and therefore lasts longer
  • Advanced safety features to reduce the risks of damaging the machine, tools, workpiece, armature, control unit(s) or hurting the operator
  • Morse taper 3 spindle with integrated tool cooling and lubrication
  • Suitable for use in areas and workplaces where power supply is of less quality
  • Timely service notification to avoid additional costs of unexpected downtime or unnecessary part replacement
  • Magnet dimension: 22L x 22B x 6.4H
  • Tapping: M3-M30

Items Included:
1x Magnetic Drilling Machine, 1x Safety Guard, 3x Handles, 1x Hex Key (2.5mm), 1x Hex Key (4mm), 1x Hex Key 5mm, 1x Lubrication System, 1x Safety Chain, 1x Bottle (200ml) Of Ibo.10 Cutting Oil, 1x Arbor Mt3 – 19.05 Weldon (3/4 Inch), Including Lubrication Ring (Imc.30/19-N), 1x Morse Taper Ejector Drift Key, 1x User Manual, 1x Safety Ear Protection, 1x Safety Goggles, 1x Safety Gloves
Item Name:
Magnetic Drilling Machine
Model:
ECO.100S+/CT
Manufacturer:
Euroboor
Color:
Grey and Black
Voltage:
220-240V
Frequency:
50-60Hz
Length:
497mm
Height:
793mm
Width:
375mm
Cutting Diameter:
12-100mm
Countersink Diameter:
10-105mm
Twist Drill Diameter:
1-32mm
Connection Size:
19.05mm
Stroke Width:
260mm
Maximum Height:
793mm
Minimum Height:
615mm
Rotation Angle:
Bidirectional
Magnetic Force:
4300 Kg
Motor Power:
1900W
Total Power:
2200W
Power Source Type:
Electric
Brand Origin (not manufacture):
Netherlands
Delivery Time:
2-7 Days
Unit:
Piece
