Fluke Industrial Electricians Combo Kit, 87-V-E2K-EUR, 10A, 1000V
(No reviews yet)
Write a Review
- Brand:
- Fluke
- SKU:
- 756987287817
- Minimum Purchase:
- 1 unit
- Item Name:
- Industrial Electricians Combo Kit
- Model:
- 87-V-E2K-EUR
- Manufacturer:
- Fluke
- Color:
- Yellow and Black
- Humidity:
- 0% - 90% (0Deg.C - 35Deg.C), 0% - 70% (35Deg.C - 55Deg.C)
- Battery Type:
- Alkaline
- Battery Life:
- 400 hrs typical, without backlight
- Storage Temperature:
- -40 to +60 Deg.C
- Safety Rating:
- EN 61010-1 to 1000V CAT III, 600V CAT IV
- Brand Origin (not manufacture):
- United States
- Certification:
- 759,7048,5042,5673
- Product Size L x B x H (Cms):
- 20.1L x 9.8B x 5.2H
- Delivery Time:
- 2-7 Days
- Unit:
- Kit
Description
The Fluke 87V/E2/EUR Industrial Electrician Combo Kit is designed and assembled in the USA. The 87V multimeter is backed by a limited lifetime warranty, so you can rely on your DMM every time you take it out of your tool box. Ideal for electricians, this combo kit is built around the Fluke 87V, the most widely used industrial digital multimeter in the world and includes essential accessories to make you even more productive. This kit offers 15% savings compared with the individual price of all the accessories. Plus you'll be working with the most trusted tools in the world. Working on VSDs/VFDs: Take accurate voltage, current and frequency measurements on the output side of the drive at either the drive itself or at the motor terminals. Industrial troubleshooting: Get the resolution and accuracy you need to solve more problems on motor drives, in-plant automation, power distribution, and electromechanical equipment. Checking power quality: Capture glitches and spikes as short as 250 ?s. Identify irregular signals.
Specifications
Voltage DC Maximum Voltage: 1000V Voltage DC Accuracy: +/-(0.05% + 1) Voltage DC Maximum Resolution: 10 µV Voltage AC Maximum Voltage: 1000V Voltage AC Accuracy: +/-(0.7% + 2) True RMS Voltage AC AC Bandwidth: 20 kHz with low pass filter; 3 db @ 1 kHz Voltage AC Maximum Resolution: 0.1 mV Current DC Maximum Amps: 10 A (20 A for 30 seconds maximum) Current DC Amps Accuracy: +/-(0.2% + 2) Current DC Maximum Resolution: 0.01 µA Current AC Maximum Amps: 10 A (20 A for 30 seconds maximum) Current AC Amps Accuracy: +/-(1.0% + 2) True RMS Current AC Maximum Resolution: 0.1 µA Resistance Maximum Resistance: 50 MOhm Resistance Accuracy: +/-(0.2% + 1) Resistance Maximum Resolution: 0.1Ohm Capacitance Maximum Capacitance: 9,999 µF Capacitance Accuracy: +/-(1% + 2) Capacitance Maximum Resolution: 0.01 nF Frequency Maximum Frequency: 200 kHz Frequency Accuracy: +/-(0.005% + 1) Frequency Maximum Resolution: 0.01 Hz Duty Cycle Maximum Duty Cycle: 99.9% Duty Cycle Accuracy: +/-(0.2% per khz +0.1%) Duty Cycle Maximum Resolution: 0.1% Temperature Measurement: -200.0 Deg.C - 1090 Deg.C, (-328.0 Deg.F - 1994.0 Deg.F excluding probe) 80 BK Temperature Probe: -40.0 Deg.C - 260 Deg.C, -40.0 Deg.F - 500 Deg.F, 2.2 Deg.C or 2% whichever is greater Conductance Maximum Conductance: 60.00 nS Conductance Accuracy: +/-(1.0% + 10) Conductance Maximum Resolution: 0.01 nS Diode Range: 3 V Diode Resolution: 1 mV Diode Accuracy: +/-(2% + 1) Duty Cycle Range Accuracy: Within +/-(02% per kHz +0.1%) Display Digital: 6000 counts updates 4/sec, 19,999 counts in high-resolution mode Analog: 32 segments, updates 40/sec Frequency: 19,999 counts, updates 3/sec at > 10 Hz Shock: 1 Meter drop per IEC 61010-1:2001 Vibration: Per MIL-PRF-28800 for a Class 2 instrument
Items Included:
Fluke 87V Industrial Multimeter, TL224 SureGrip Insulated Test Leads, AC220 SureGrip Alligator Clips, TL238 SureGrip Test Probes, ToolPak Magnetic Meter Hanging Kit, 80BK-A DMM Temperature Probe, C35 Soft Carrying Case, 9V battery (installed)
View AllClose
Specifications
- The Fluke 87V/E2 Industrial Electrician Combo Kit is designed and assembled in the USA. The 87V multimeter is backed by a limited lifetime warranty, so you can rely on your DMM every time you take it out of your tool box.
- True-rms ac voltage and current for accurate measurements on non linear signals
- Selectable filter for accurate voltage and frequency measurements on motor drives
- 4-1/2 digit mode for precise measurements
- Built-in thermometer lets you carry one less tool
- Large display digits and two-level bright white backlight for increased visibility
- 10;000 µF capacitance range for components and motor caps
- Peak capture to record transients as fast as 250 µs
- Auto and manual ranging for maximum flexibility
- Resistance; continuity and diode test
- Frequency to 200 kHz and % duty cycle
- Min/Max and average recording to capture variations automatically
- Relative mode to remove test lead resistance from low ohms measurements
- Improved sleep mode for long battery life
Items Included:
Fluke 87V Industrial Multimeter, TL224 SureGrip Insulated Test Leads, AC220 SureGrip Alligator Clips, TL238 SureGrip Test Probes, ToolPak Magnetic Meter Hanging Kit, 80BK-A DMM Temperature Probe, C35 Soft Carrying Case, 9V battery (installed)
Item Name: |
Industrial Electricians Combo Kit |
Model: |
87-V-E2K-EUR |
Manufacturer: |
Fluke |
Color: |
Yellow and Black |
Humidity: |
0% - 90% (0Deg.C - 35Deg.C), 0% - 70% (35Deg.C - 55Deg.C) |
Battery Type: |
Alkaline |
Battery Life: |
400 hrs typical, without backlight |
Storage Temperature: |
-40 to +60 Deg.C |
Safety Rating: |
EN 61010-1 to 1000V CAT III, 600V CAT IV |
Brand Origin (not manufacture): |
United States |
Certification: |
759,7048,5042,5673 |
Product Size L x B x H (Cms): |
20.1L x 9.8B x 5.2H |
Delivery Time: |
2-7 Days |
Unit: |
Kit |
