Schneider Electric Molded Case Circuit Breaker, NSX160F, ComPacT, 4P, IP40, 160A
- Brand:
- Schneider Electric
- SKU:
- 954998365468
- Minimum Purchase:
- 1 unit
- Item Name:
- Molded Case Circuit Breaker
- Model:
- NSX160F
- Product Series:
- ComPacT
- Manufacturer:
- Schneider Electric
- Color:
- Black
- Manufacture Part Number:
- C16F6TM160
- Width (MilliMeter):
- 140mm
- Height (MilliMeter):
- 165mm
- Number of Poles:
- 4P
- Control Type:
- Toggle
- Insulation Voltage:
- 800VAC
- Frequency:
- 50/60 Hz
- Operational Voltage:
- 690VAC
- Depth:
- 86mm
- Mounting Type:
- Fixed Backplate
- Current:
- 160A
- Ingress Protection (IP Rating):
- IP40
- IK Rating:
- IK07
- Over Load Protection (Yes/No):
- Yes
- Relative Humidity:
- 0-95%
- Storage Temperature:
- -50 to 85 Deg.C
- Brand Origin (not manufacture):
- France
- Standards:
- EN/IEC 60947
- Certification:
- 13437,5043,17960
- Delivery Time:
- 2-7 Days
- Unit:
- Piece
Description
This ComPacT NSX160F is a complete 4P 3d fixed circuit breaker designed to optimize space and breaking capacity. It is an optimal choice for all standard and specific applications. The breaking capacity (Icu) is 36kA rms at 415VAC 50/60Hz. The operational voltage is 690VAC 50/60Hz. This product embeds a 160A rating thermal-magnetic trip unit (TMD). TMD trip unit provides an adjustable thermal overload protection and a fixed magnetic protection. This 4 poles version comes with a variety of optional functions and accessories. It is compliant with international standards (IEC 60947), CCC, EAC and marine specifications.
View AllClose
- Neutral Position: Left
- Network Type: AC
- Utilisation Category: Category A
- Performance Level: F 36 kA 415VAC
- Trip Unit Name: TM-D
- Rated impulse withstand voltage: 8kV
- Mechanical Durability: 40000 cycles
- Power dissipation per pole: 13.95W
- Long-time pick-up adjustment type Ir (thermal protection): Adjustable
- Long-time protection pick-up adjustment range: 0.7-1 x ln
- Number of slots for electrical auxiliaries: 5 Slots
