Schneider Electric NSX160B Molded Case Circuit Breaker, C16B6TM160, ComPacT, 4P, 25 kA, 415VAC, 160A

(No reviews yet) Write a Review
Brand:
Schneider Electric
SKU:
931564258231
Minimum Purchase:
1 unit
Item Name:
Molded Case Circuit Breaker
Model:
C16B6TM160
Product Series:
ComPacT
Manufacturer:
Schneider Electric
Color:
Black
Width (MilliMeter):
140mm
Height (MilliMeter):
161mm
Number of Poles:
4P
Control Type:
Toggle
Insulation Voltage:
800VAC
Frequency:
50/60 Hz
Operating Ambient Temperature (Degree Celsius):
-25 to 70 Deg.C
Breaking Capacity:
25 kA at 415VAC
Pitch:
35mm
Trip Type:
Thermal-magnetic
Depth:
86mm
Current:
160A
Ingress Protection (IP Rating):
IP40
IK Rating:
IK07
Relative Humidity:
0-95%
Operating Altitude:
0 to 5000 Mtrs
Storage Temperature:
-50 to 85 Deg.C
Brand Origin (not manufacture):
France
Standards:
EN/IEC 60947
Certification:
13437,5043,17960
Delivery Time:
2-7 Days
Unit:
Piece
See Full Product Specs
AED802.00

Description

This ComPacT NSX160B is a complete 4P 3d fixed circuit breaker designed to optimize space and breaking capacity. It is an optimal choice for all standard and specific applications. The breaking capacity (Icu) is 25kA rms at 415VAC 50/60Hz. The operational voltage is 690VAC 50/60Hz. This product embeds a 160A rating thermal-magnetic trip unit (TMD). TMD trip unit provides an adjustable thermal overload protection and a fixed magnetic protection.
  • Neutral Position: Left
  • Network Type: AC
  • Utilisation Category: Category A
  • Performance Level: B 25 kA 415VAC
  • Trip unit name: TM-D
  • Circuit Breaker Mounting Mode: Fixed
  • Rated Impulse Withstand Voltage: 8 kV
  • Mechanical Durability: 40000 Cycles
  • Power Dissipation per Pole: 13.95W
  • Mounting Support: Backplate
  • Mounting Position: Horizontal and Vertical Flat on the back
  • Number of Slots for Electrical Auxiliaries: 5
  • Overvoltage Category: Class II
